Name: 200NM torque measurement 100Nm torque sensor 50NM torque transducer
Brand: Forsentek
Price: 1 USD

Brand Name : Forsentek

Model Number : FTG

Place of Origin : China

MOQ : 1pc

Payment Terms : T/T,Western Union or Paypal

Supply Ability : 5000pcs/month

Delivery Time : 3~20 working days

Packaging Details : 1pc/box

Usage : Torque measurement

Theory : Strain gauge torque sensor

Output : Analog Sensor

Capacity : 10NM 20NM 30NM 50NM 100NM 150NM 200NM

Torque measure direction : Clockwise and counterclockwise

Contact Now

200NM torque measurement 100Nm torque sensor 50NM torque transducer

Features

Specifications

Rated capacity	10NM 20NM 30NM 50NM 100NM 150NM 200NM
Rated output	1.5mV/V
Excitation	3-15V
Zero balance	±2% R.O.
Nonlinearity	±0.2% R.O.
Hysteresis	±0.2% R.O.
Nonrepeatability	±0.1% R.O.
Creep(10min)	±0.1% R.O.
Safe overload	150% F.S.
Ultimate overload	200% F.S.
Compensated temp.	-10...+40^oC
Operating temp.	-20...+60^oC
Temp. shift zero	±0.02% R.O./^oC
Temp. shift span	±0.01% R.O./^oC
Input resistance	350±30 ohms
Output resistance	350±10 ohms
Insulation resistance	>5000M ohms
Ingress protection	IP50
Material of element	Stainless steel
Cable	Ø5.5*3000mm
Wiring code	Red--Exc+ Black--Exc- Green--Sig+ White--Sig-

Flange-to-flange reaction type torque sensor FTG

200NM torque measurement 100Nm torque sensor 50NM torque transducer

Dimensions

200NM torque measurement 100Nm torque sensor 50NM torque transducer
